nRF7001 Wi-Fi 6 Companion IC

Low-power, advanced security, seamless coexistence

With decades of expertise in ultra-low-power wireless IoT and silicon design, Nordic is now bringing its know-how to Wi-Fi, providing added benefits to IoT applications, including further efficiency gains that support long-life, battery-powered Wi-Fi operation. The nRF7001 Wi-Fi 6 companion IC is an innovative IC designed to seamlessly enable Wi-Fi 6 connectivity in various applications.

The nRF7001 is the second device in Nordic's nRF70 Series of Wi-Fi companion ICs, which combines effortlessly with Nordic's existing ultra-low power technologies. Designed to work alongside Nordic's nRF52 and nRF53 Series Bluetooth SoCs, and nRF91 Series cellular IoT SiPs, the nRF7001 can also be used with non-Nordic host devices.

The nRF7001 features a 2.4 GHz radio with low power consumption, ensuring extended battery life, and advanced security features to protect user data. The nRF7001 is a cost-efficient yet powerful solution for adding the latest Wi-Fi 6 technology to products. It offers fast and reliable connectivity, advanced security features, and is designed for easy integration into a wide range of applications. With the nRF7001 Wi-Fi 6 companion IC, developers can now leverage the latest Wi-Fi 6 technology to create innovative and cutting-edge IoT products that offer improved speeds, extended range, and greater reliability.

With Wi-Fi 6 we support all wireless protocols used in Matter, Bluetooth LE for commissioning, Thread for low power mesh, and Wi-Fi for high-throughput. Matter is a protocol championed by Apple, Amazon, Google, Nordic Semiconductor, Samsung, and hundreds of other companies in consumer IoT.

Download PDF  Download nRF7001 product brief [PDF]



Ask us about this
Key features
  • Low-power and secure Wi-Fi for the IoT
  • Ideal coexistence with Bluetooth LE
  • Supported in nRF Connect SDK
  • Target Wake Time (TWT)
  • SPI / QSPI
  • Wi-Fi 6 Station (STA)
  • SoftAP
  • Wi-Fi Direct
  • Complies with 802.11b/g/n/ax
  • 1 Spatial Stream (SS)
  • 20 MHz channel bandwidth
  • 64 QAM (MCS7), 86 Mbps PHY throughput
  • OFDMA (Downlink and Uplink)
  • BSS coloring
  • WPA3 Personal and Enterprise
  • Co-existence interfaces
Documentation
Downloads

Reference layout

Selected version
1.1 QFAx Layout and BOM resources

Changelog:

1.1 QFAx Layout and BOM resources

1.0 QFAx Layout and BOM resources

Changelog:

  • Updated connectivity for separate DCDC GND net BUCKVSS and positions of external components.

0.11 QFAx Layout and BOM resources
